Model Name

24B36X

Panel Type

23.8" IPS

Pixel Pitch

0.2745 (H) × 0.2745 (V) mm

Effective Viewing Area

527.04 (H) × 296.46 (V) mm

Brightness (Typical)

300 cd/m²

Contrast Ratio

1500:1 (typical) / MEGA DCR

Response Time

4 ms GtG / 0.5 ms MPRT

Viewing Angle

178° (H) / 178° (V) (CR > 10)

Color Gamut

NTSC 112% (CIE1976) / sRGB 123% (CIE1931)

Optimum Resolution

1920 × 1080 @ 144 Hz

Display Colors

16.7 million

Signal Input

1× HDMI 1.4, 1× DisplayPort 1.4

USB Hub

No

Power Supply

External 19V DC, 1.31 A

Power Consumption (Typical)

18 W

Speakers

No

Line In / Earphone

Yes

Wall Mount

100 × 100 mm

Adjustable Stand

Tilt: −5° ~ 23°

Dimensions (Without Stand)

318.5 (H) × 544.0 (W) × 35.1 (D) mm

Dimensions (With Stand)

414.5 (H) × 544.0 (W) × 198.0 (D) mm

Packaging Dimensions

420 (H) × 615 (W) × 112 (D) mm

Weight (Without Stand)

2.21 kg

Weight (With Stand)

2.52 kg

Weight (With Packaging)

4.65 kg

Cabinet Color

Black

Regulatory Approvals

CE / FCC / RoHS
