General

Phase

Single Phase

Form Factor

Tower

UPS Topology

Line-interactive

Energy Saving Technology

GreenPower UPS™ Bypass Technology

Input

Generator Compatibility

Yes

Nominal Input Voltage (Vac)

230 ± 10%

Input Voltage Range (Vac)

167 ~ 295

Input Frequency (Hz)

50 / 60

Input Frequency Detection

Auto-sensing

Rated Input Current (A)

10

Input Connector Type

Schuko

Power Cord Length (ft)

5

Power Cord Length (m)

1.5

Output

Capacity (VA)

2200

Capacity (Watts)

1320

On Battery Waveform

Simulated Sine Wave

On Battery Voltage(s) (Vac)

230 ± 10%

On Battery Frequency (Hz)

50 ± 1% / 60 ± 1%

Automatic Voltage Regulation (AVR)

Single Boost, Single Buck

Overload Protection

Internal Current Limiting, Circuit Breaker

Outlet(s) – Total

4

Outlet Type

Schuko x 4

Outlet(s) – Battery & Surge Protected

4

Typical Transfer Time (ms)

4

USB Charging Port(s)

USB-A x1, USB-C x1

USB Charging Total Output

5V / 2.1A

Battery

Runtime at 60W (min)

95

Runtime at 90W (min)

70

Runtime at 200W (min)

34

Typical Recharge Time (Hours)

8

Start On Battery

Yes

User-replaceable

No

Battery Type

Sealed Lead-acid

Surge Protection & Filtering

Surge Suppression (Joules)

150

EMI/RFI Filtration

Yes

Phone/Network Protection RJ11/RJ45 (Combo)

1-in, 1-out

Management & Communications

LED Indicators

Power On, Line Mode, Battery Mode, Bypass Mode, Low Battery, Overload, UPS Fault

HID Compliant USB Port(s)

1

Audible Alarms

Battery Mode, Low Battery, Overload, UPS Fault

Ethernet Data Transmission Speed

Up to 1Gbps

Power Management Software

PowerPanel Personal (Recommended)

Physical

Enclosure Construction

Plastic

Color

Black

Dimensions (WxHxD) (in)

5.83 x 7.01 x 11.73

Dimensions (WxHxD) (mm)

148 x 178 x 298

Weight (lbs)

23.81

Weight (kg)

10.8

Shipping Dimensions (in)

10.67 x 7.95 x 15.63

Shipping Dimensions (mm)

271 x 202 x 397

Shipping Weight (lbs)

24.47

Shipping Weight (kg)

11.1

Environmental

Operating Temperature (°F)

32 ~ 104

Operating Temperature (°C)

0 ~ 40

Operating Relative Humidity

0 ~ 90% (non-condensing)

Operating Elevation

0 – 9,843 ft (0 – 3,000 m)

Storage Temperature (°F)

-4 ~ 122

Storage Temperature (°C)

-20 ~ 50

Storage Relative Humidity

0 ~ 90% (non-condensing)

Storage Elevation

0 – 9,843 ft (0 – 3,000 m)

Online Thermal Dissipation (BTU/hr)

34.1

Audible Noise at 1.5M

50 dBA

Certifications

Certifications

CE

RoHS

Yes
