Application

Intel Socket LGA775/115X/1200/1366/2011/2066

AMD Socket AM2/AM3/AM4/AM5/FM1/FM2

Application (V2)

Intel Socket LGA115x/1200/1700/2011/2066

AMD Socket AM2/AM3/AM4/AM5/FM1/FM2

Water Block

Dimension

61mm (L) x 61mm (W) x 50mm (H)

Material

Copper base with plastic body

Pump

Motor Speed

3400±10% RPM

Rated Voltage

12V*

Rated Current

0.39A

Radiator

Dimension

153mm (L) x 120mm (W) x 28mm (H)

Material

Aluminum

Tube

Length

400mm

Material

Rubber

Fan

Dimension

120mm (L) x 120mm (W) x 25mm (D)

Speed

600~2200RPM

Noise Level

7.4~35.6 dBA

Rated Voltage

12V

Rated Current

0.32A

Max Airflow

94CFM

Max Air Pressure

3.53mm/H2O

Connector

4 Pin PWM & 4-1 Pin ARGB (5V LED)

Remark

* Please confirm that the header that supplies power to the PUMP has a stable 12V voltage. It’s recommended to disable the PWM/DC mode of this header from the motherboard BIOS, or to set it to full speed
